Body material | Magnesium alloy | 마그네슘 합금 |
Sensor | • 35.8 x 23.9 mm CMOS sensor *
• Full 35 mm size frame *
• RGB Color Filter Array
• Built-in fixed low-pass filter
• 13.3 million total pixels *
• 12.8 million effective pixels *
• 3:2 aspect ratio | • 로우패스필터는 1D급 제품에 비해 저렴한 것이 채용되었다 합니다. |
Image processor | DIGIC II | • 1D mark II 이후로 같은 DIGIG II입니다. |
Image sizes | • 4368 x 2912 (L; 12.7 MP) *
• 3168 x 2112 (M; 6.7 MP) *
• 2496 x 1664 (S; 4.2 MP) * |
|
File formats | • RAW (.CR2; 12-bit)
• JPEG (EXIF 2.21) - Fine / Normal
• RAW + JPEG (separate files) | • 12-bit입니다. |
File sizes | • RAW: approx. 12.9 MB
• Large / Fine: approx. 4.6 MB
• Large / Normal: approx. 2.3 MB
• Medium / Fine: approx. 2.7 MB
• Medium / Normal: approx. 1.4 MB
• Small / Fine: approx. 2.0 MB
• Small / Normal: approx. 1.0 MB | • 1G메모리로는 RAW 촬영시 80장 정도 RAW + L Fine 촬영시 60매도 촬영하기 힘듭니다. |
Color space | • sRGB
• Adobe RGB |
|
Lenses | • Canon EF lens mount (does not support EF-S lenses) *
• No field of view crop (1.0x) * | • EF-S 렌즈는 마운트되지 않습니다. |
Focusing | • 9-point TTL
• 6 "Invisible Assist AF points" *
• CMOS sensor
• AF working range: -0.5 to 18 EV (at 20°C, ISO 100) * | • 9개의 측거점과 6개의 보이지 않는 AF 포인트를 제공합니다. |
Focus modes | • AI Focus AF
• One shot AF
• AI Servo AF
• Manual focus |
|
AF point selection | • Auto
• Manual
• Home position |
|
AF assist | No * |
|
Metering | • TTL 35 zone SPC
• Metering range: 1.0 to 20 EV (at 20°C, ISO 100, 50 mm F1.4) |
|
Metering modes | • Evaluative 35 zone
• Partial (8% at center*)
• Spot metering (3.5% at center) *
• Center-weighted average
• Metering range: 1 - 20 EV (at 20°C, ISO 100) | • 스팟측광을 드디어 지원합니다. |
AE lock | • Auto: One Shot AF with evaluative metering
• Manual: AE lock button |
|
AE bracketing | • +/- 2.0 EV
• 0.3 or 0.5 EV increments |
|
Exposure compen. | • +/-2.0 EV
• 0.3 or 0.5 EV increments |
|
Sensitivity * | • Auto (ISO 100 - 400)
• ISO 50 (Enhanced L) *
• ISO 100
• ISO 125
• ISO 160
• ISO 200
• ISO 250
• ISO 320
• ISO 400
• ISO 500
• ISO 640
• ISO 800
• ISO 1000
• ISO 1250
• ISO 1600
• ISO 3200 (Enhanced H) | • ISO 50을 지원합니다. |
Shutter | • Focal-plane shutter
• 30 - 1/8000 sec
• 0.3 or 0.5 EV increments
• Flash X-Sync: 1/200 sec *
• Bulb | • 1/8,000초까지 지원합니다. |
Aperture values | • F1.0 - F91
• 0.3 or 0.5 EV increments
• Actual aperture range depends on lens used |
|
White balance | • Auto (3000 - 7000 K)
• Daylight (5200 K)
• Shade (7000 K)
• Cloudy (6000 K)
• Tungsten (3200 K)
• Fluorescent (4000 K)
• Flash (6000 K)
• Custom (2000 - 10000 K)
• Kelvin (2800 - 10000 K in 100 K steps) |
|
WB bracketing | • +/-3 levels
• 3 images
• blue/amber or magenta/green bias |
|
WB shift | • Blue (-9) To Amber (+9)
• Magenta (-9) to Green (+9) |
|
Picture style * | • Standard
• Portrait
• Landscape
• Neutral
• Faithful
• Monochrome
• User 1
• User 2
• User 3 | • 20D부터 지원한 흑백을 지원합니다. 후보정을 귀찮아 하시는 분들에게는 좋은 기능입니다. |
Custom image parameters * | • Sharpness: 0 to 7
• Contrast: -4 to +4
• Saturation: -4 to +4
• Color tone: -4 to +4
• B&W filter: N, Ye, Or, R, G
• B&W tone: N, S, B, P, G | • Image parameter의 setting 범위가 커졌습니다. |
Viewfinder | • Eye-level pentaprism
• 96% frame coverage *
• Magnification: 0.71x *
• Eyepoint: 20 mm
• Dioptric adjustment: -3 to +1 diopter
• Precision matte screen Ee-A (removable *) | • 96%의 시야율은 보통 필름 카메라와 유사합니다. |
Viewfinder info | • AF points
• Focus confirmation light
• Shutter speed
• Aperture
• Manual exposure
• AE Lock
• Exposure compensation amount
• AEB level
• Spot metering circle
• Flash ready
• Red-eye reduction lamp on
• High-speed sync
• FE Lock
• Flash compensation amount
• Warnings
• Maximum burst for continuous shooting
• Buffer space |
|
LCD monitor | • 2.5" TFT LCD *
• 230,000 pixels *
• 5 brightness levels
• 10x zoom playback | • 2.5인치의 23만 화소는 좋아졌습니다. |
Shutter release | • Soft touch * | • 셔터감은 20D와는 다릅니다. |
Record review | • Off
• On (histogram via INFO button)
• 2 / 4 / 8 sec / Hold |
|
Histogram | • Luminance
• RGB * |
|
Flash | • No built-in flash unit *
• E-TTL II auto flash / metered manual
• Flash compensation +/-2.0 EV in 0.3 or 0.5 EV increments
• X-Sync: 1/200 sec *
• Hot-shoe &PC Terminal | • 내장 플래쉬가 없습니다. |
Shooting modes * | • Auto
• Program AE (P)
• Shutter priority AE (Tv)
• Aperture priority AE (Av)
• Manual (M)
• Custom | • Scene 모드가 없고, 사용자의 custom 정보를 하나 넣을 수 있습니다. |
Drive modes | • Single
• Continuous: 3 fps up to 60 JPEG / 17 RAW frames *
• Self-timer: 10 sec (3 sec with mirror lock-up) | • 초당 3연사이며 60연사 (jpg) 가능합니다. |
Burst buffer | • RAW+JPEG: 12 frames
• RAW: 17 frames
• Large/Fine JPEG: 60 frames
• Large/Normal JPEG: 150 frames
• Medium/Fine JPEG: 120 frames
• Medium/Normal JPEG: Unlimited
• Small/Fine JPEG: 200 frames
• Small/Normal JPEG: Unlimited |
|
Direct printing | • Canon Compact Photo Printers
• Canon PIXMA Printers supporting PictBridge
• PictBridge | • 거의 필요 없는 기능인 것 같습니다. |
Orientation sensor | Yes |
|
Auto rotation | • On (playback uses orientation data in file header)
• Off |
|
Playback mode | • Single image
• Single image with info (inc. histogram)
• Magnified view (1.5 - 10x in 15 steps, browsable)
• 9 image index
• Image rotation
• Jump (by 10 or 100 images, by date, by folder *) |
|
Custom functions | 21 custom functions with 57 settings * |
|
Menu languages | • English
• German
• French
• Dutch
• Danish
• Finnish
• Italian
• Norwegian
• Swedish
• Spanish
• Simplified Chinese
• Japanese
• Traditional Chinese
• Korean
• Russian | • 한글 지원합니다. 20D부터 지원했던 것 같습니다. |
Firmware | User upgradable |
|
Portrait grip | Via BG-E4 battery grip (optional) * |
|
Wireless | Via WFT-E1 (optional) |
|
Connectivity | • USB 2.0 Hi-Speed
• Video out
• N3 type wired remote control
• PC Sync flash terminal |
|
Storage | • Compact Flash Type I or II
• Microdrive supported
• Support for cards over 2 GB (FAT32)
• No CF card supplied |
|
Power | • Lithium-Ion BP-511A rechargeable battery (supplied &charger)
• Supports BP-511 / BP-511A / BP-512 / BP-514
• CR2016 Lithium battery (date/time backup)
• Optional AC adapter | • 10D, 20D와 같은 배터리를 씁니다. |
Dimensions | 152 x 113 x 75 mm (6.0 x 4.4 x 2.9 in) * | • 20D보다 크지만 1D보다 작습니다. |
Weight (no batt) | 810 g (1.8 lb) * | • 20D에 비해 150 g 정도 무겁습니다. |
Weight (inc. batt) | 895 g (2.0 lb) * |
|
